DZ4

High Magnification & High Resolution Zoom Microscope

Zoom Ratio of 12 : Stepless Magnification Change from 349.8x to 4200x without changing lens (with objective ZC70). It is possible to reach the observation position quickly at low magnification and magnify the image then and there to the maximum. DZ4 can be used with various types of illuminations. It has a wide application. The resolution is so high that a very clear picture is available even when the microscope is used with a large monitor.
█ DZ4 Specifications of Main Unit
DZ4-T(Manuai Type)DZ4-E(Motorized Type)
Correction SystemAfocal
Zoom Ratio12
Image Sizeφ8mm(1/2 CCD applicable, with C-Mount)
Length Overall174.5mm
Weight900g1250g
exclusive of objective,camera & LED
Illnmination SystemCoaxial Reflecting Illumination
OptionRing Illumination, Motorized Focus Unit, Camera, Stand, etc
█ Specifications of Objectives
Type of ObjectivesZC5ZC15ZC30ZC50ZC70
Optical Magnification0.42~5X1.25~15X2.5~30X4.2~50X5.8~70X
Total Magnification*25~300X75~900X150~1800X250~3000X350~4200X
W.D.45mm46mm35mm14mm7.1mm
Resolution33.6?4.8µm11.2?1.7µm5.6?0.9µm3.4?0.8µm2.4?0.5µm
Weight190g150g396g250g550g
*The above total magnification is obtained with 1/2inchCCD & 19inchTV Monitor
Download PDF leaflet  DZ4
